SAFETY WIRE NUT AND IMPERIAL BOLT DRILL JIG KIT

WMP | SKU: TMD14K359A

WMP Safety Wire Nut And Imperial Bolt Drill Jig Kit

$100.95
$102.99
$100.95

Best price guarantee

Found it cheaper? Call us and we'll match it.
Subtotal: $100.95
🚚 Local pick-up isn't offered, but we've got you covered with fast, reliable shipping — dispatched in 1–3 days.

Explore related collections:

SAFETY WIRE NUT AND IMPERIAL BOLT DRILL JIG KIT

WMP Safety Wire Nut And Imperial Bolt Drill Jig Kit

$102.99 $100.95
SAFETY WIRE NUT AND IMPERIAL BOLT DRILL JIG KIT

WMP Safety Wire Nut And Imperial Bolt Drill Jig Kit

$102.99 $100.95
  • Two-piece kit: separate nut drill jig and bolt drill jig
  • Nut jig accepts nuts up to 1-3/8" diameter
  • Bolt jig covers six imperial sizes: 1/4"-20, 5/16"-24, 5/16"-18, 3/8"-16, 3/8"-24 and 7/16"-14
  • Guides the bit for a straight hole without slipping off the fastener
  • Drills holes up to 2mm — requires a 2mm or smaller drill bit (not included)
  • Allows critical nuts and bolts to be safety wired against vibration loosening
  • Suits scrutineering and race preparation as well as general workshop use
  • Works with WMP safety wire (HWSSW0705KG, HWSSW0710M, HWSSW12) and safety wire pliers (TMPSWS, TMPSWL)
  • Nut drill jig
  • Imperial bolt drill jig
BrandWMP (Whites Motorcycle Parts)
Model / Part NumberTMD14K359A
TypeSafety wire drill jig kit (imperial)
Kit ContentsNut drill jig and bolt drill jig
Nut Jig CapacityUp to 1-3/8" diameter nuts
Bolt Jig Sizes1/4"-20, 5/16"-24, 5/16"-18, 3/8"-16, 3/8"-24, 7/16"-14
Maximum Hole Size2mm (drill bit not included)
Measurement StandardImperial
Barcode9420060968880
  • Match the jig to the fastener first — use the bolt jig hole that corresponds to the thread size, or the nut jig for nuts up to 1-3/8".
  • Secure the jig firmly on the fastener before drilling so the guide bushing sits square to the flat.
  • Use a 2mm or smaller drill bit; anything larger will not pass through the guide and can damage the jig.
  • Run the drill at a moderate speed with steady, light pressure rather than forcing it, and back the bit out periodically to clear swarf.
  • A drop of cutting oil on the bit helps with hardened fasteners and extends bit life.
  • Deburr the drilled hole and blow or brush the fastener clean before threading safety wire through it.
  • Clear metal filings from the guide holes after each job so the jig continues to seat flush.
  • Wipe the jigs clean and apply a light film of oil before storing to prevent surface rust.
  • Store the kit dry, and inspect the guide holes occasionally — a worn or bell-mouthed guide will no longer hold the bit straight.
  • Always wear eye protection when drilling, and clamp loose fasteners in a vice rather than holding them by hand.
